Laser Distance Sensor

SW-LDS-DA/DB

Measurement Frequency:1Hz~40Hz

Measuring Range: 0.2m-20m/30m/50m

Supports 64 units for networked operation and PLC programming

Output Ports: RS232/RS485, 2-channel switch output voltage/current output

IP67 protection, metal die-cast body, ensures stability even outdoors and in harsh environments

Laser Type: Class II 650±15nm, <1mW

Built-in screen and menu, can be set up without connecting to a computer

Voltage Output Error: 0.2%+0.5mV (DB series only)

Current Output Error: 0.2%+0.005mA (DB series only)

Operating Mode: Single measurement, Continuous measurement

Voltage/Current Output: 0~5V/0~10V/4~20mA/0~20mA/0~24mA (DB series only)
